GPS/GPRS/HSDPA VT10 - 3G

VT10-3G is multifunctional GPS / GSM vehicle tracking unit for real-time location and collecting telemetry data from vehicles or any other moving assets. It has advanced features for controlling external vehicle systems and devices, such as fuel meter, temperature sensor, driver identification system, and also provides voice monitoring and voice communication.

Special User Defined Interface (UDI) allows to read CAN bus, use OBDII scanner tool, integrate with iButton devices or extend number of inputs and outputs. Optional equipment kits extend the capabilities of VT10-3G. There are hands-free voice communication kit, RFID driver identification kit, microphone for cabin monitoring and other accessories available.

VT10-3G can be embedded with 2G or 3G GSM module. Broadband connection is used for fast data transmission, i.e. video or images, as well as for Internet surfing via USB interface.

  • Communication by Voice, CS Data, SMS, GPRS UDP/TCP for 2G
  • Communication by Voice, SMS, Edge, UMTS and HSDPA for 3G
  • Configurable Tracking & Logging mode, by Time interval, Distance interval, Speeding changes,Heading changes and IG status
  • GPS/GSM antenna tempering alert
  • GSM Jamming alert (optional)
  • Geo-fencing control
  • Mileage report
  • Power Low/Lost alert
  • Towing away alert
  • Speeding alert
  • Power Management
  • Roaming preference settings
  • Maximum 100 settings in user defined reports
  • Internet Surfing via USB connection
  • Configuration over the air
  • Firmware upgrading over the air
  • Dimensions (Lx W x H): 115: 75: 32 mm
  • Casing : ABS plastic
  • GPS Module : 66 channels high sensitivity GPS receiver
  • Communication : Quad -band 850/900/1800/1900 MHz in 2G,GSM/GPRS or Tr -band 850/900/2100 MHz in 3G UMTS/HSDPA
  • Power Source : DC 8-40V
  • Power Consumption in sleeping mode: <10uA@ DC 3.7V, back-up battery power supply condition <4mA@ DC 12V, main power supply condition
  • Memory Capacity : 4MB, storage over 100,000 waypoints
  • System Setting : 100 user defined events
  • Device Ports : 4 input ports, with 2 positive triggering and 2 negative triggering (includes 2 analog) 4 output ports, 4 negative triggering 1 serial port, TTL/RS232 switching by command 1 mini USB port for configuration
  • GPS Antenna : External (SMA connector type) and Internal
  • GSM Antenna : External (SMA connector type) and Internal
  • Motion Sensor : Tr -axial acceleration sensor
  • Back-up Battery : Lithium battery with 860mAH capacity
  • Operating Temperature: -20°C — 80°C (without back-up battery condition)
  • User Defined Interface(UDI):Optional
  • 2.4 GHz RF Transceiver:Optional
  • External GSM Antenna
  • External GPS Antenna
  • Power/Input/Output Cable
  • Serial Cable
  • Water Proof Casing
  • Input/Output Extension Box
  • Audio Box and RF Dialer
  • RS232 Extension Hub
  • Trailer Tracker Kit
  • Radio Beacon
  • 4-button Remote Controller
  • Video Camera
  • RFID Reader and Tag
  • iButton
  • Wireless and Wired Temperature Sensor
  • Wi-Fi 802.11b/g Modem
  • OBDII Scan Tool
